Sơ mi rơ moóc kiểu sàn FGM 3 mới

- Loading platform geometry to be defined: straight chassis or drop rear tail (ref. technical drawing)
- Hardwood sp 30 mm reference technical drawing
- N. 8x2 certified lashing rings, payload 8.000 kg, recessed within the loading platform
- N. 18x2 certified lashing holes, payload 5.000 kg, installed on the lateral sides of the semitrailer
- Position holes for twist locks: N.2x20" container, N.1x40" container
- Telescopic chassis of MAX 6.000 mm, adjusting positions each 500 mm, pneumatically lockable
- Chassis entirely made of high strength steel, SSAB STRENX ® 700 / S 420 MC
- 2-Speed front landing gear, payload 24.000 kg, Jost Modul. Surface treatment: Black finish
- N.3 axles with pneumatic suspensions, BPW make, 12-ton, disk brakes
- Third axle self-steering
- Braking system, Knorr Bremse make, equipped with EBS
- N.6 brake levers, self-adjusting
- N. 1 Pneumatic valve for adjustment height of load + 12 cm / - 5 cm
- Semitrailer electric system, Aspöck systems make, entirely LED, MultiLED II
- Hot dipped galvanized chassis + Painting of Trailer sides, RAL Color of your choice
- 2 Stainless steel toolboxes dim. L 1000x H 300 x W 500 mm
- N.4 Wide load signs, adjustable extension, dimensions 423x423 mm, equipped with N. 2 LED lights for each panel.
Extendable up to 3,000 mm width
- N. 6 Tires 435/50 r 19.5 Continental M+S, Steel rims
- Aluminum air tanks
- Predisposition to install rear aluminum ramps
- N.2 Aluminum side protection bars
- European Homologation (COC)
- Warranty program 1 year

Note:
- We offer Professional Delivery Service
- Temporary license plate
- Eur-1/ EX customs documents for export


Contacts: hiện liên lạc

German speaking salesperson + 39 347 72 60 640
English speaking salesperson + 39 333 90 81 295


* Prices are intended exclusively for the vehicle in stock.
Demonstrative photos, ask us to connect you with local dealer for more information/ prices regarding models to be produced
